L Series Contactor

L Series contactors are hermetically sealed, non latching switching devices rated for 90 amps in both AC and DC configurations. They’re perfect for both military and commercial aircraft applications. Special models with auxiliary contacts are available.

This contactor is specially designed to meet MIL-PRF-6106 standards.

  • 50,000 minimum operating cycles at resistive load
  • 100,000 minimum operating cycles at 25% resistive load
Category: Industry:

Get In Touch With Our Experts!

Product Characteristics

Product Characteristics

Contact Voltage115/200 Vac,28 Vdc
Coil FrequencyN/A
Coil Voltage (DC)28
Contact Frequency (Hz)400
Current (Amps)90
Contact Arrangement1PDT,3PDT
StyleNon-latching
Max Dimensions (inches)3.38 x 3.58 x 3.32
Sealing TypeHermetic
Weight1.7 lbs max

Contact Electrical Characteristics

Contact rating per pole and load type 28 Vdc 115 Vac
400 Hz		 115/200 Vac
400 Hz, 3Ø		 28 Vdc [3] 115 Vac
400 Hz [3]
Resistive 50 90 90 120 120
Inductive [2] 30 90 90 80 120
Motor 30 80 80 80 80

Coil Characteristics (Vdc)

CODE A
Vdc		 N [5]
Vdc
Nominal operating voltage 28 28
Maximum operating voltage 29 29
Pick-up voltage, maximum
Nominal 18 18
High temp test 20 20
Continuous current test 22.5 22.5
Drop-out voltage, maximum 7 7
Coil resistance in Ohms ±10% at +25° C 65 65
Coil current Amp max. @ nom. Volt.and +25° C 0.475 0.475

General Characteristics

Temperature range -55°C to +71°C
Minimum operating cycles (life) at rated resistive load 50,000
Minimum operating cycles (life) at 25% rated resistive load 100,000
Dielectric strength at sea level
All circuits to ground and circuit to circuit 1,500 Vrms
Coil to ground and aux. contacts 1,000 Vrms
Dielectric strength at altitude
Main contacts 700 Vrms
Coil and aux. contacts 500 Vrms
Insulation resistance
Initial (500 Vdc) 100 M Ω min
After environmental tests 50 M Ω min
Sinusoidal vibration 10 G / 55 to 1,000 Hz
Shock (10-12 ms duration) 15 G
Maximum contact opening time under vibration and shock 10 µs
Operate time at nominal voltage (Including bounce) 40 ms max
Release time at nominal voltage (Including bounce)
– DC 40 ms max
– AC 100 ms max
Contact bounce at nominal voltage 4 ms max
Weight Noted
Overload at 115/200 Vac, 400 Hz 630 Amps
Rupture at 115/200 Vac, 400 Hz 900 Amps
Altitude 50,000 Feet
